Series ZN（5.0~50cc/rev）
Inlet: 1
Outlet: 1
Capacity: 5.0~50cc/rev
Working Pressure: ≤25Mpa
Working Temperature: ≤330℃ (Customizable for higher temperatures)
The temperature depends on the sealing ring material and pump body material
Rotational Speed: 5-40r/min
It should be used with reduced speed and pressure for high viscosity or non lubricating fluids
Main applications: Spinning of nylon, Polypropylene, Polyester, Carbon fiber, etc
(Special media require replacement of pump body materials)
Outlet: 1
Capacity: 5.0~50cc/rev
Working Pressure: ≤25Mpa
Working Temperature: ≤330℃ (Customizable for higher temperatures)
The temperature depends on the sealing ring material and pump body material
Rotational Speed: 5-40r/min
It should be used with reduced speed and pressure for high viscosity or non lubricating fluids
Main applications: Spinning of nylon, Polypropylene, Polyester, Carbon fiber, etc
(Special media require replacement of pump body materials)
