Type A2（1.0~1.8cc/rev）

Inlet: 1

Outlet: 16

Capacity: 1.0~1.8cc/rev

Working Pressure: ≤10Mpa

Working Temperature: ≤220℃ (Customizable for higher temperatures)
The temperature depends on the sealing ring material and pump body material

Rotational Speed: 10-80r/min
It should be used with reduced speed and pressure for high viscosity or non lubricating fluids

Application: Adhesive dispensing, Glue filling, Coating, Paints, Pressure increasing, Metering, etc

Medium: Adhesive, hot melt adhesive, polyurethane, paints, ink, oils, resin, lotion, organic solvent, various additives, etc.
Special media require replacement of pump body materials
